Thermal Shock

Product Description

Thermal Shock For Ceramic Tiles

Applications:

• To determine the Resistance to thermal shock of Ceramic tiles.

• Designed for cooling ceramic tiles by immersing them in water
• Suitable for sizes of up to 5050 cm.
• If the glazed tiles are showing an absorption coefficient  10% (m/m), then they must be immersed in a Vertical Thermal Tank
• Fitted with flowmeter to maintain water flow rate of of 4 lt/min
• Fitted with microprocessor based digital controller to maintain temperature of 15 5 C
• Has sufficient depth to allow the tiles to be placed vertically, immersed and so that are not in contact with each other.
• Water drainage outlet with pipe fitring
• Stainless steel bucket for samples

• Designed for the indirect cooling of ceramic tiles, without immersion
• Suitable for sizes of up to 50 50 cm
• If the glazed tiles are showing an absorption coefficient >10% (m/m), then an operator must use Horizontal Thermal Tank
• Complete stainless steel tank structure
• Aluminum plate of 5 mm thickness is kept inside the tank.
• Flowmeter to maintain 4 lt/min water flow rate
• Microprocessor based digital controller to maintain temperature of 15 5 C
• Water drainage outlet with pipe fitting
• Stainless steel bucket for samples
• Supplied complete with a 5 kg pack of aluminum granules of different diameters (from 0.3 to 0.6 mm)
